Solanki HDPE Sprinkler Pipes with Quick-Coupling and C-Clamp latch mechanism conform to IS 14151 (Part 1 & 2), offering high-efficiency micro-irrigation for modern agriculture.
Automated HDPE extrusion combined with factory butt-fusion welded couplers for robust, zero-leakage agricultural micro-irrigation systems.
Automated in-line process control — melt temperature, line speed, wall thickness, and coupler weld integrity are monitored continuously to spec for durable, leak-free performance in demanding farm environments.
High UV & stress-crack resistance
Rapid shifting across farm fields
High-retention EPDM rubber rings
Solanki HDPE Sprinkler Systems conform strictly to Indian Standards IS 14151 Part 1 (Pipes) and Part 2 (Quick-Action Couplers).
HDPE Pipes for Sprinkler Irrigation
Quick-Action Couplers & Accessories
Verified virgin polymers, continuous extrusion monitoring, precision coupler butt-fusion, and hydrostatic test batteries.
Tier-1 PE resin (IOCL · GAIL · Reliance) verified for Melt Flow Rate, density & carbon dispersion before extrusion.
Wall thickness, ovality, and robotic coupler fusion weld strength monitored on every single batch by QC engineers.
Full IS 14151 test battery on finished pipes and quick couplers — hydrostatic burst, leak testing, and latch pull-out.
Comprehensive in-house testing capabilities strictly conforming to IS 14151 Part 1 & Part 2.
Quick-Coupled HDPE Sprinkler Pipes conforming to IS 14151 (Part 1 & 2).
| Nominal OD (mm) | Pressure Class | Working Pressure (kg/cm²) | Wall Thickness (mm) | Coupling Mechanism |
|---|---|---|---|---|
| 50 mm | Class 1 / Class 2 | 2.5 - 3.2 kg/cm² | 1.50 - 2.00 mm | C-Clamp / Quick Latch |
| 63 mm | Class 1 / Class 2 / Class 3 | 2.5 - 4.0 kg/cm² | 1.80 - 2.80 mm | C-Clamp / Quick Latch |
| 75 mm | Class 1 / Class 2 / Class 3 / Class 4 | 2.5 - 6.0 kg/cm² | 2.10 - 3.70 mm | C-Clamp / Quick Latch |
| 90 mm | Class 1 / Class 2 / Class 3 / Class 4 | 2.5 - 6.0 kg/cm² | 2.60 - 4.50 mm | C-Clamp / Quick Latch |
| 110 mm | Class 1 / Class 2 / Class 3 / Class 4 | 2.5 - 6.0 kg/cm² | 3.20 - 5.50 mm | C-Clamp / Quick Latch |
Discover seamless field installation, 360° uniform spray coverage, and pressure-sealed quick coupler operations.
Watch how effortlessly farmers can assemble, operate, and re-position our quick-coupling sprinkler systems for 40-50% water savings and higher yields.
Engineered rubber gaskets prevent pressure leakage even under dynamic farm topography.
Solanki HDPE Sprinkler Pipes are engineered specifically to cater to agricultural micro-irrigation and water conservation. Manufactured conforming to IS 14151 (Part 1 for Pipes & Part 2 for Quick-Action Couplers), these piping systems provide uniform water dispersion simulating natural rainfall over crops. Fitted with high-strength fusion-welded couplers and rugged latch clamps, our sprinkler pipes allow effortless tool-free assembly and dismantling in the field. Farmers can shift complete pipelines from one acre to another in minimal time without specialized tools or labor. Constructed using premium UV-stabilized High Density Polyethylene, Solanki Sprinkler Pipes withstand prolonged direct sunlight exposure, aggressive weather fluctuations, and high operating pressures without degradation or cracking.
Manufactured strictly in accordance with BIS standards Part 1 & 2.
Rapid tool-free assembly and dismantling in agricultural fields.
Formulated with carbon black additives for prolonged sunlight exposure.
Prevents soil erosion and water run-off with uniform spray.
Easily shifted and loaded on tractors by a single person.
Specially designed rubber ring seal retains pressure under fluctuating flow.
Compatible with liquid fertilizers and chemigation treatments.
Rugged build ensures 15+ years of trouble-free field deployment.
Partner with Solanki Industries for high-efficiency sprinkler piping solutions engineered for water conservation, farmer prosperity, and maximum crop yield.
